2CPX208R-V3 2CPX208R-V3
4-port multibeam antenna, 4x 790–960 MHz, 2x 38° HPBW, 2x RET with manual override.
2CPX208R-V3
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, low band: 4
2CPX208R-V3
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, low band: 4
2H-33A-R2 2H-33A-R2
4-port multibeam antenna, 4x 1695–2400 MHz, 2x 38° HPBW, 2x RET
2H-33A-R2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
2H-33A-R2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
2HH-38A-R4-V2 2HH-38A-R4-V2
8-port multibeam antenna, 8x 1695–2200 MHz, 4x 38° HPBW, 4x RET
2HH-38A-R4-V2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2HH-38A-R4-V2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2NN2HH-33B-R4 2NN2HH-33B-R4
16-port multibeam antenna, 8x 698–896 MHz, 2x 2-beam 33° HPBW and 8x 1695–2400 MHz, 2x 2-beam 33° HPBW, 4x RET
2NN2HH-33B-R4
  • Product Type: Sector antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 8
2NN2HH-33B-R4
  • Product Type: Sector antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 8
2NN2HH-33C-R4 2NN2HH-33C-R4
16-port multibeam antenna, 8x 698–896 MHz, 2x 2-beam 33° HPBW and 8x 1695–2400 MHz, 2x 2-beam 33° HPBW, 4x RET
2NN2HH-33C-R4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 8
2NN2HH-33C-R4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 8
2SS-33A-R1 2SS-33A-R1
8-Port multibeam antenna ,8x 3100-4200 MHz , 4x 33° HPBW, 1x RET
2SS-33A-R1
  • Product Type: Multibeam antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, high band: 8
2SS-33A-R1
  • Product Type: Multibeam antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, high band: 8
2UNPX206.12R2 2UNPX206.12R2
8-port multibeam antenna, 4x 698–894 and 4x 1710-2180 MHz, 4x 35° HPBW, 4x RET
2UNPX206.12R2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 4
  • RF Connector Quantity, low band: 4
2UNPX206.12R2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 4
  • RF Connector Quantity, low band: 4
2UPX210B-T2 2UPX210B-T2
4-port multibeam antenna, 4x 694–896 MHz, 2x 37° HPBW, 2x RET with manual override.
2UPX210B-T2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, low band: 4
2UPX210B-T2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, low band: 4
2VV-33C-R4 2VV-33C-R4
8-port multibeam antenna, 8x 1695–2690 MHz, 4x 33° HPBW, 4x RET
2VV-33C-R4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2VV-33C-R4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2VV-33C-R4-V4 2VV-33C-R4-V4
8-port multibeam antenna, 8x 1695–2690 MHz, 4x 33° HPBW, 4xRET
2VV-33C-R4-V4
  • Product Type: Multibeam antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2VV-33C-R4-V4
  • Product Type: Multibeam antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2VV-33C-R4-V5 2VV-33C-R4-V5
8-port multibeam antenna, 8x 1695–2690 MHz, 4x 33° HPBW, 4x RET
2VV-33C-R4-V5
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2VV-33C-R4-V5
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2VV-33C-R4-V6 2VV-33C-R4-V6
8-port multibeam antenna, 8x 1695–2690 MHz, 4x 33° HPBW, 4x RET, has tilt scales
2VV-33C-R4-V6
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2VV-33C-R4-V6
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
